48V 120Ah Golf Cart Battery High Power Rechargeable Lifepo4 Lithium Ion Battery Pack
* Safe Battery Chemistry: Our EV battery series are designed with LiFePO4 chemistry battery which has been widely recognized as one of the safest battery technologies.
LiFePO4 chemistry features stable structures with low toxicity, well-defined performance, long-term stability.
Automotive Standard Cell & Battery Structure Technology : engineer & technician team bring our expertise at automotive battery R&D and manufacturing standards and technology to the design and structure of the storage batteries.
The cells inside are automotive-grade high quality cells, capable of high C-rate charge/discharge to support critical loads such as air condition, water pumps, EV charging, etc.
* Easy Installation and Stackablity: Storage batteries are modular-designed featuring easy installation and stackable up to 16 modules to meet higher energy consumption.
* Wide Compatibility: Storage batteries have commissioned for communication and compatibility with the major inverter and more inverter and charger brand.
Specification of 48V 120AH Golf Cart Battery High Power Rechargeable Lifepo4 Lithium Ion Battery Pack
|
Model Number |
48V lithium iron phosphate battery pack |
|
Place of Origin |
China Guangdong |
|
Norminal voltage |
51.2V |
|
Norminal capacity |
120Ah |
|
Life cycle |
3500 times typical at 0.5C discharge 25℃ |
|
Stored energy |
6.1Kwh |
|
Self-discharge rate |
≤3% /month |
|
Weight |
52kg |
|
Recom.charging current |
≤60A |
|
Recom.charging current |
120A |
|
Max continuous discharging current |
200A |
|
Max discharging current (15 seconds) |
400A |
|
Peak discharging current |
600A |
|
Charger CC/CV |
58.4V |
|
Storage Type |
Golf cart electric sightseeing four-wheel patrol car low-speed car |
|
Working temperature |
-20℃~60℃ |
|
Storage temperature |
-10℃~35℃ |
|
Charge Temp. |
0-50℃ |
|
Disharge Temp. |
-20-60℃ |
|
Protection function |
Overcharge,overdischarge,over current,short curcuit protection |
|
Casing material |
Cold rolled steel with powder coated |
|
Color |
Yellow or Customize |
|
Dimension |
L500*W360*H260 mm |
|
IP Rate(waterproof) |
IP65 |
